1000BPH Barreled Dej Tag Nrho Kab Qaib ntxhw Project

Qhov project nta

Yuav tsum muaj cua ntws, Nm³ / h:

400

Qhov chaw:

Qhov siab, m:

10

Suction max. kub, ºC:

40

Tso Tawm Siab, bar:

40

Lwm tus:

HORIZON 400

Ua kom tiav pob

Reciprocating, nyob ruaj ruaj, nyob rau hauv kab rov tav kev npaj thiab sib npaug compressor. DOUBLE ACTING, Peb theem ntawm COMPRESSION, nrog crossheads, dej-txias, tsis muaj cylinders LUBRICATION.

Compressor ntim kev tsim kho ntawm cov hlau nplaum nrog hluav taws xob, pneumatic, qhov cua sib txuas. tsim thiab sim ntawm lub Hoobkas.

Kev faib tawm

CE

Keeb kwm

Spain

Flow & huab cua zoo

Ua kom muaj txiaj ntsig zoo, m³ / h FAD:

431

Ua kom muaj txiaj ntsig zoo, Nm³ / h:

371

Lub zog ntawm lub crankshaft, kW:

65

Suction siab, kg / cm² (a):

1032

Tso zis siab, bar (g):

40

Huab cua zoo, raws li ISO 8573-1: 2010:

100% Roj tsis muaj lub tog raj kheej

Cov roj /

Chav Kawm 1 /

Particle /

Chav Kawm 1 /

Humidity /

Chav Kawm 4 /

Kev tiv thaiv:

IP -23 (*)

Kev ua tau zoo:

IE 2

Lub zog, kW:

75

Ceev, RPM

1.500

Lub zog, V:

400

Zaus, Hz:

50

(*) Txuj kev tiv thaiv dej nag nrog qhov siab tshaj plaws ntawm 60 degrees. Nyob rau hauv rooj plaub ntawm kev teeb tsa sab nraum zoov lossis raug dej ntau dua, thov, sab laj nrog lwm txoj kev tiv thaiv.

Kev sib txuas

HORIZON

Coupling ntawm lub cev muaj zog thiab reducer; Kev ua haujlwm siab iav reducer

Coupling ntawm reducer thiab lub cev muaj zog

Hluav taws xob txee

AUTOMATIC WYE DELTA PIB

Tswj los ntawm relays thiab lub teeb qhia. Centralized hais kom ua rau tag nrho cov khoom siv peripheral. Kev tiv thaiv IP-54.

Cov cuab yeej

Siab thiab kub hloov thiab ntsuas.

Tus txais

Peev xwm: 500 litres.

HORIZON

Lub tshuab ziab khaub ncaws

Lub tshuab ziab khaub ncaws, haum rau saum huab cua compressor, WATER condenser, +3 degree dew point nrog tsis siv neeg ntws. SUBMICRONIC filtering system ntawm lub tshuab ziab khaub ncaws. Haum nrog phaj exchangers hauv STAINLESS STEEL.

Cov dej ntws

Tsis siv neeg tso dej teeb, hom capacitive, ntawm cov cua txias thiab receiver.

Phau ntawv

Hauv Lus Askiv

Qauv

BS-18.5A/10

(Rau Ref. nkaus xwb)

Lub cev muaj zog

25 HP / 18.5KW TSI

Hwj chim

380V / 50Hz

Huab cua xa

3.0m³hauv 10kg

Siab

8-10kg cm2

Txias

Cua Txias

Cov ntsiab lus roj

2ppm ua

Suab nrov (1m Facade)

62dB ib

Hom

Roj Txhaj Ob Chav Twin Ntsia Hlau

Temp ntawm Outlet

Ambient Temp +15 degree

Qhov hluav taws xob

RP 1 * 1/2

Kev sib kis

Direct Coupling

Qhov hnyav

700 KGS

Dimension (L * W * Hmm)

1500*840*1180

Tswj

Nws pib load / unloading, Unloading ncua

Kev tiv thaiv

Overload tiv thaiv, Rov qab Theem Tiv Thaiv, Tshaj Kub Tiv Thaiv

Daim ntawv pov thawj

Warranty, Test Report, Operation Manuel, Spare Parts Manuel

Keeb kwm

Shanghai

Muaj peev xwm

600L

Max. Siab

10 kg / cm2

Txoj kab uas hla

700 hli

Qhov siab

18 60mm

Khoom siv

Galvanized hlau

Keeb kwm

Shanghai

(Rau Ref. nkaus xwb)

Qauv

SHJL{0}.5/1.0

Muaj peev xwm

4.5m3 / min

Lub zog txias txias

1.1 TSI

Max. Intake Temp.

45 degree

Max. Siab

10kg / cm2

Ambient Temp.

38 degree

Hwj chim

1P 380V / 50Hz

Dew Point

2-10 degree

Qhov Loj (L * W * H mm)

650*500*910

Qhov hnyav

9 5 KG

Qhov hluav taws xob

RC 1 * 1/2

Qauv

Qib C

T Qib

A Qib

H Qib

Muaj peev xwm

4.5 m³ / min

4.5 m³ / min

4.5 m³ / min

4.5 m³ / min

Max. Siab

16kg / cm2

16kg / cm2

16 kg / cm2

16kg / cm2

Khoom Hla-Section

Khoom siv

Fiberglass

Silicon fiber ntau

Silicon fiber ntau

Cov pa roj carbon activated

Max. Cua Temp.

66 degree

66 degree

66 degree

30 degree

Muaj nuj nqi

Pre-filter rau 5μm txoj kab uas hla plua plav particle, rusted av, khib nyiab, thiab lwm yam.

Primary Lim rau 1μm particle

Secondary Lim rau 0.01μm particle

Purifying tsw.
